ZYX BLOOM VX
spécifications
détaillées
options disponibles - ZN ecrous TB tin base ou SB silver base
|
| R50 Bloom VX |
Moving Coil (Dynamic) |
| Output Voltage |
0.24mV / 0.48mV H |
| Frequency Response |
10 Hz - 100 kHz |
| Channel Separation |
＞ 30dB 〔 1kHz 〕 |
| Channel Balance |
＜ 0.5dB 〔 1kHz 〕 |
| Recommended Tracking Force |
2.0gm 〔 20 ゜C-25 ゜C 〕 |
| Tracking Force Range |
1.7gm - 2.5gm |
| Trackablity |
＞ 60μm / 2.0g |
| EQ Compliance |
horizontal |
|
vertical |
|
15×10-6cm/dyne
12×10-6cm/dyne |
| Internal Impedance |
4.0 ΩH / 8 OHM (H) |
| Load Impedance |
＞ 100 ΩHM |
| Coil Wire |
6N Copper Wire φ0.03mm
|
| Cantilever Material |
black ALM g5 tube φ0.45/ φ0.30mm |
| Stylus |
Line-contact Solid Diamond □ 0.1mm |
| Contact Radius, Life Time |
6μm×60μm, 2000Hour/2.0gm |
| Output Terminals |
φ1.25mm gold plated 〔 EIA 〕 |
| Dimensions W x L x H mm |
16.2 x 19.7 x 17.6 |
| Net Weight - seule / + TB / + SB |
5g / 7.7g / 9g |
|
| Ultimate R100 VX |
Moving Coil (Dynamic)
|
| Cryogenic Treatment |
Temperature: -196 ℃ (-320оF) |
| Output Voltage |
0.24mV / 0.48mV (H) |
| Frequency Response |
10 Hz - 100 kHz
|
| Channel Separation |
＞ 30dB 〔 1kHz 〕 |
| Channel Balance |
＜ 0.5dB 〔 1kHz 〕 |
| Recommended Tracking Force |
2.0gm 〔 20 ゜C-25 ゜C 〕 |
| Tracking Force Range |
1.7gm - 2.5gm |
| Trackablity |
＞ 60μm |
| EQ Compliance |
horizontal |
| |
vertical |
|
15×10-6cm/dyne
12×10-6cm/dyne |
| Internal Impedance |
4 ΩHM / 8 OHM (H) |
| Load Impedance |
＞ 100 ΩHM |
|
|
6N OFC Crystal Copper |
| Cantilever Material |
C-1000 composite CARBON 0.30mm |
| Stylus |
Micro-Ridge Solid Diamond 0.1mm |
| Contact Radius, Life Time |
3μm×60μm, 2000Hour/2.0gm |
| Output Terminals |
φ1.25mm K18 Solid Gold 〔 EIA 〕 |
| Terminal Board |
glass epoxy plate |
|
Dimensions W x L x H
|
16.2 x 19.7 x 17.6 mm |
| Net Weight - seule / + TB / + SB |
5g / 7.7g / 9g |
|
ZYX ULTIMATE 100 VX
spécifications
détaillées
options disponibles - ZN ecrous TB tin base ou SB silver base
|
| |
|
|
ZYX ULTIMATE AIRY VX
spécifications
détaillées
options disponibles - ZN ecrous TB tin base ou SB silver base
|
| Ultimate Airy VX |
Moving Coil (Dynamic)
|
| Cryogenic Treatment |
Temperature: -196 ℃ (-320°F) |
| Output Voltage |
0.24mV / 0.48mV (H)
|
Frequency Response
±1dB |
10 Hz - 100 kHz
20 Hz - 20 kHz |
| Channel Separation |
＞ 30dB 〔 1kHz 〕 |
| Channel Balance |
＜ 0.5dB 〔 1kHz 〕 |
| Recommended Tracking Force |
2.0gm 〔 20 ゜C-25 ゜C 〕 |
| Tracking Force Range |
1.7gm - 2.5gm |
| Trackablity |
＞ 60μm |
| EQ Compliance |
horizontal |
| |
vertical |
|
15×10-6cm/dyne
12×10-6cm/dyne |
| Internal Impedance |
X et XX 4 ΩHM / 8 OHM (H)
S 2.5 OHM / 4 OHM (H)
|
| Load Impedance |
＞ 100 ΩHM |
|
Coil Wire
|
X type
|
| |
XX type |
| |
S type
|
|
6N Crystal Copper φ.035mm/CRYO
Large crystal copper
5N Silver
|
| Cantilever Material |
C-1000 CARBON 0.30mm |
| Stylus |
Micro-Ridge Solid Diamond 0.1mm |
| Contact Radius, Life Time |
3μm×60μm, 2000Hour/2.0gm |
| Output Terminals |
φ1.25mm gold plated 〔 EIA 〕 |
| Dimensions W x L x H |
16.2 x 19.7 x 17.6 mm |
| Net Weight - seule / + TB / + SB |
5g / 7.7g / 9g |
|
| |
|
| Ultimate 4D VX |
Moving Coil (Dynamic)
|
| Cryogenic Treatment |
Temperature: -196 ℃ (-320оF) |
| Output Voltage |
0.24mV / 0.48mV (H)
|
Frequency Response
|
10 Hz - 100 kHz
|
| Channel Separation |
＞ 30dB 〔 1kHz 〕 |
| Channel Balance |
＜ 0.5dB 〔 1kHz 〕 |
| Recommended Tracking Force |
2.0gm 〔 20 ゜C-25 ゜C 〕 |
| Tracking Force Range |
1.7gm - 2.5gm |
| Trackablity |
＞ 60μm |
| EQ Compliance |
horizontal |
| |
vertical |
|
15×10-6cm/dyne
12×10-6cm/dyne |
| Internal Impedance |
X et XX 4 ΩHM / 8 OHM (H)
S 2.5 OHM / 4 OHM (H)
|
| Load Impedance |
＞ 100 ΩHM |
|
Coil Wire
|
X type
|
| |
XX type |
| |
S type
|
|
6N Crystal Copper φ.035mm/CRYO
Large crystal copper
5N Silver
|
| Cantilever Material |
C-1000 composite CARBON 0.30mm |
| Stylus |
Micro-Ridge Solid Diamond 0.07mm |
| Contact Radius, Life Time |
3μm×60μm, 2000Hour/2.0gm |
| Output Terminals |
φ1.25mm gold plated 〔EIA〕 |
|
Dimensions W x L x H
|
16.8 x 19.0 x 15.6 mm |
| Net Weight - seule / + TB / + SB |
4.1g 6.8g / 8g |
|
ZYX ULTIMATE 4D VX
spécifications
détaillées
options disponibles - TB tin base ou SB silver base
options inclus - ZN ecrous
|
| |
|
|
ZYX ULTIMATE OMEGA VX
spécifications
détaillées
options disponibles - SB silver base
options inclus - ZN ecrous TB tin base
|
| Ultimate Omega VX |
Moving Coil (Dynamic)
|
| Cryogenic Treatment |
Temperature: -196 ℃ (-320оF) |
| Output Voltage |
0.24mV / 0.48mV (H)
|
| Frequency Response |
10 Hz - 100 kHz
|
| Channel Separation |
＞ 30dB 〔 1kHz 〕 |
| Channel Balance |
＜ 0.5dB 〔 1kHz 〕 |
| Recommended Tracking Force |
2.0gm 〔 20 ゜C-25 ゜C 〕 |
| Tracking Force Range |
1.7gm - 2.5gm |
| Trackablity |
＞ 60μm |
| EQ Compliance |
horizontal |
| |
vertical |
|
15×10-6cm/dyne
12×10-6cm/dyne |
| Internal Impedance |
X et XX 4 ΩHM / 8 OHM (H)
S 2.5 OHM / 4 OHM (H)
|
| Load Impedance |
＞ 100 ΩHM |
|
Coil Wire
|
X type
|
| |
XX type |
| |
S type
|
|
6N Crystal Copper φ.035mm/CRYO
Large crystal copper
5N Silver
|
| Cantilever Material |
C-1000 composite CARBON 0.30mm |
| Stylus |
Micro-Ridge Solid Diamond 0.1mm |
| Contact Radius, Life Time |
3μm×60μm, 2000Hour/2.0gm |
| Output Terminals |
φ1.25mm K18 Solid Gold 〔 EIA 〕 |
| Terminal Board |
Composite CARBON Plate |
|
Dimensions W x L x H
|
16.8 x 25.0 x 16.5 mm |
| Net Weight - avec TB / + SB |
7.9g / 9.1g |
|
| |
|
| Ultimate Astro VX |
Moving Coil (Dynamic)
|
| Cryogenic Treatment |
Temperature: -196 ℃ (-320оF) |
| Output Voltage |
0.15mV (3.54cm/sec, 1kHz) |
| Frequency Response |
10 Hz - 100 kHz
|
| Channel Separation |
＞ 30dB 〔 1kHz 〕 |
| Channel Balance |
＜ 0.5dB 〔 1kHz 〕 |
| Recommended Tracking Force |
2.0gm 〔 20 ゜C-25 ゜C 〕 |
| Tracking Force Range |
1.7gm - 2.5gm |
| Trackablity |
＞ 60μm |
| EQ Compliance |
horizontal |
| |
vertical |
|
15×10-6cm/dyne
12×10-6cm/dyne |
| Internal Impedance |
X et XX 4 ΩHM / 8 OHM (H)
S 2.5 OHM / 4 OHM (H)
|
| Load Impedance |
＞ 100 ΩHM |
|
Coil Wire
|
X type
|
| |
XX type |
| |
S type
|
|
6N Crystal Copper φ.035mm/CRYO
Large crystal copper
5N Silver
|
| Cantilever Material |
C-1000 composite CARBON 0.30mm |
| Stylus |
Micro-Ridge Solid Diamond 0.1mm |
| Contact Radius, Life Time |
3μm×60μm, 2000Hour/2.0gm |
| Output Terminals |
φ1.25mm K18 Solid Gold 〔 EIA 〕 |
| Terminal Board |
Composite CARBON Plate |
|
Dimensions W x L x H
|
16.8 x 19.0 x 16.5 mm |
| Net Weight - avec TB / + SB |
7.9g / 9.1g |
|
ZYX ULTIMATE ASTRO VX
spécifications détaillées
options disponibles - SB silver base
options inclus - ZN ecrous TB tin base
|
| |
|
|
ZYX ULTIMATE DIAMOND VX
spécifications détaillées
options disponibles - SB silver base
options inclus - ZN ecrous TB tin base
|
| Ultimate Diamond VX |
Moving Coil (Dynamic)
|
| Cryogenic Treatment |
Temperature: -196 ℃ (-320оF) |
| Output Voltage |
0.24mV / 0.48mV (H)
|
| Frequency Response |
10 Hz - 100 kHz
|
| Channel Separation |
＞ 30dB 〔 1kHz 〕 |
| Channel Balance |
＜ 0.5dB 〔 1kHz 〕 |
| Recommended Tracking Force |
2.0gm 〔 20 ゜C-25 ゜C 〕 |
| Tracking Force Range |
1.7gm - 2.5gm |
| Trackablity |
＞ 60μm |
| EQ Compliance |
horizontal |
| |
vertical |
|
15×10-6cm/dyne
12×10-6cm/dyne |
| Internal Impedance |
X et XX 4 ΩHM / 8 OHM (H)
S 2.5 OHM / 4 OHM (H)
|
| Load Impedance |
＞ 100 ΩHM |
|
Coil Wire
|
X type
|
| |
XX type |
| |
S type
|
|
6N Crystal Copper φ.035mm/CRYO
Large crystal copper
5N Silver
|
| Cantilever Material |
Natural Diamond0.22mm |
| Stylus |
Micro-Ridge Solid Diamond 0.1mm |
| Contact Radius, Life Time |
3μm×60μm, 2000Hour/2.0gm |
| Output Terminals |
φ1.25mm K18 Solid Gold 〔 EIA 〕 |
| Terminal Board |
Composite CARBON Plate |
|
Dimensions W x L x H
|
16.8 x 25.0 x 16.5 mm |
| Net Weight - avec TB / + SB |
7.9g / 9.1g |
|
| |
|
| Ultimate ASTRO DIAMOND VX |
Moving Coil (Dynamic)
|
| Cryogenic Treatment |
Temperature: -196 ℃ (-320оF) |
| Output Voltage |
0.24mV / 0.48mV (H)
|
| Frequency Response |
10 Hz - 100 kHz
|
| Channel Separation |
＞ 30dB 〔 1kHz 〕 |
| Channel Balance |
＜ 0.5dB 〔 1kHz 〕 |
| Recommended Tracking Force |
2.0gm 〔 20 ゜C-25 ゜C 〕 |
| Tracking Force Range |
1.7gm - 2.5gm |
| Trackablity |
＞ 60μm |
| EQ Compliance |
horizontal |
| |
vertical |
|
15×10-6cm/dyne
12×10-6cm/dyne |
| Internal Impedance |
X et XX 4 ΩHM / 8 OHM (H)
S 2.5 OHM / 4 OHM (H)
|
| Load Impedance |
＞ 100 ΩHM |
|
Coil Wire
|
X type
|
| |
XX type |
| |
S type
|
|
6N Crystal Copper φ.035mm/CRYO
Large crystal copper
5N Silver
|
| Cantilever Material |
C 1000 carbon f0.30mm |
| Stylus |
Micro-Ridge Solid Diamond 0.1mm |
| Contact Radius, Life Time |
3μm×60μm, 2000Hour/2.0gm |
| Output Terminals |
φ1.25mm K18 Solid Gold 〔 EIA 〕 |
| Terminal Board |
Composite CARBON Plate |
|
Dimensions W x L x H
|
16.8 x 25.0 x 16.5 mm |
| Net Weight - avec TB / + SB |
7.9g / 9.1g |
|
ZYX ULTIMATE
ASTRO-DIAMOND VX
spécifications
détaillées
options disponibles - SB silver base
options inclus - ZN ecrous TB tin base
|
|
|
|
